Video Processing Flow
Chapter
Chapter 3 Signal Selection and Transitions
3
Signal Selection and
Transitions
Video Processing Flow
The switch from the current video stream (appearing on
the corresponding program monitor) to a new video stream
is referred to as a transition.
The following illustration shows the flow of operations for
carrying out a transition on an M/E bank or the PGM/PST
bank.
Select next transition (page 68)
Make key settings (page 89)
Keys 1 to 8
Select new background video (page 64)
Select transition type (page 68)
Select current background video (page 64)
Background
Cut Mix
Super mix Preset color mix
Wipe
DME wipe
Make wipe settings
(page 124)
Make DME wipe settings
(page 144)
Preview the effect of transition (page 83)
Execute the transition (page 77)
