149
Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
Setting the timing of transition completion
When the execution mode for a DME wipe crop transition
is set to [Last 5%], you can select the timing of transition
completion from 70% ([Last 30%]), 95% ([Last 5%]), and
100% ([Off]).
1
In the M/E 1 >DME Wipe menu, select HF5 ‘Modify.’
The Modify menu appears.
2
In the <Crop Mode> group select [Remove From
Begin].
The Remove From Begin menu appears.
3
In the <Release Transition> group, select the timing of
transition completion.
Last 30%: The transition completes at the end of 70%
of the transition execution time. The transition has
a dead zone from 70% to 95% of the transition
time.
Last 5%: The transition completes at the end of 95%
of the transition execution time. When the
transition completes, the cropping is removed
during the last 5% (enlarges).
Off: The transition completes at the end of the
transition execution time. During the last 5% of
the transition, the transition and cropping removal
proceed together.
DME Wipe Modify Clear
Press [Default Recall] at the lower left of the menu display,
turning it on, then press VF6 ‘DME Wipe’ to return the
DME wipe settings to their initial status.
For details of the menu operation to return the DME wipe
state to that set in initial status, see “Returning to Default
State in Function Groupings” (page 60).
Transition
t: transition execution time
y: change in transition and
cropping amount
Cropping
“Dead Zone”
Transition
t: transition execution time
y: change in transition and
cropping amount
Cropping
To Next Page
