Figure 100: M320 Router Serial Number ID Label on PIC
For T320 routers, the serial number ID label is located on the right side of the PIC Figure
101 on page 246 when the PIC is vertically oriented (as it would be installed in the router).
The exact location may be slightly different on different PICs, depending on the placement
of components on the PIC board.
Figure 101: T320 Router Serial Number ID Label on PIC
For T640 and T1600 routers, the serial number label is located on the right side of the
PIC (Figure 102 on page 247) when the PIC is vertically oriented (as it would be installed
in the router). The exact location may be slightly different on different PICs, depending
on the placement of components on the PIC board.
Copyright © 2012, Juniper Networks, Inc.246
M Series and T Series Routers Monitoring and Troubleshooting Guide
