Some PICs, such as Gigabit Ethernet PICs, accept small form-factor pluggable tranceivers
(SFPs), which are fiber-optic transceivers that can be removed from the PIC.
The M10i router provides a maximum aggregate throughput of 12.8 gigabits per second
(Gbps). Control operations in the router are performed by the Routing Engine, which runs
Junos OS to handle routing protocols, traffic engineering, policy, policing, monitoring, and
configuration management. Forwarding operations in the router are performed by the
Packet Forwarding Engine.
Related
Documentation
M10i Router Components on page 9•
M10i Router Components
Table 5 on page 9 lists the major M10i router components and characteristics.
Table 5: M10i Router Major Hardware Components
Offline
Button
Field-
ReplaceableRedundantFunctionQuantityComponent
YesHot-pluggableYesProvides route lookup, filtering, and
switching on incoming data packets;
directs outbound packets to the
appropriate FPC for transmission to the
network
1 or 2CFEB
–Hot-removable,
hot-insertable
YesCools router components2 fan
trays (8
fans)
Cooling system
–Built-in–House the PICs that connect the router to
network media
2FPC
–Hot-pluggableWorks with a companion Routing Engine
to provide control and monitoring
functions for router components; displays
alarm status; takes PICs online and offline
2HCM
Yes
(On
the
HCM)
Hot-removable,
hot-insertable
–Provides interfaces to various network
media; receives incoming packets from the
network and transmits outgoing packets
to the network, performing framing and
line-speed signaling for their media type;
encapsulates outgoing packets received
from the FPCs before transmitting them.
1–8PIC
YesHot-removable,
hot-insertable
YesDistributes needed voltages to
components
1–4
AC or DC
Power supply
–Hot-removable,
hot-insertable
–Fiber-optic transceivers that connect to
PICs
SFP
9Copyright © 2012, Juniper Networks, Inc.
Chapter 1: M Series Multiservice Edge Routers
