CHAPTER 36
Monitoring Redundant SFMs
•
Monitoring Redundant SFMs on page 683
•
Redundant SFMs Overview on page 685
•
Check M40e Router Redundant SFM Configuration on page 686
•
Understand M40e Router Redundant SFM Operation on page 687
•
Understand M160 Router Redundant SFM Operation on page 687
•
Display Redundant SFM Hardware Information on page 687
•
Monitor Redundant SFM Status on page 688
•
Display M40e Router Redundant SFM Mastership on page 693
•
Display Redundant SFM Alarms on page 695
•
Verify SFM Failure on page 697
•
Control Redundant SFMs on page 698
•
Replace an SFM on page 700
Monitoring Redundant SFMs
Purpose To monitor redundant Switching and Forwarding Modules (SFMs) and ensure that traffic
transiting the router is handled properly. SFMs contain the Internet Processor II
application-specific integration circuits (ASICs), which make forwarding decisions, and
the Distributed Buffer Manager ASICs, which distribute data cells throughout memory
and forward notification of outgoing packets. (See Table 153 on page 683.)
Action Table 153: Checklist for Monitoring Redundant SFMs
Command or ActionMonitor Redundant SFM Tasks
“Check M40e Router Redundant SFM Configuration” on page 686
“Understand M40e Router Redundant SFM Operation” on page 687
“Understand M160 Router Redundant SFM Operation” on page 687
show chassis hardware
“Display Redundant SFM Hardware
Information” on page 687
“Monitor Redundant SFM Status” on page 688
