Figure 193: T320, T640, and T1600 Router Routing Engine Component

TX Matrix Router Routing Engine

Figure 194 on page 370 shows the Routing Engine component (RE 600) used on the TX

Matrix router.

Figure 194: TX Matrix Router Routing Engine Component

NOTE: The TX Matrix Router supports RE-600-2048 (EOL), RE-1600-2048

(EOL), and RE-A-2000-4096

TX Matrix Plus Router Routing Engine

Figure 195 on page 371 shows the Routing Engine component used on the TX Matrix Plus

router.
