CHAPTER 39
Monitoring Redundant CFEBs
•
Checklist for Monitoring the CFEBs on page 729
•
Redundant CFEBs Overview on page 730
•
Display Redundant CFEB Hardware Information on page 731
•
Display CFEB Mastership on page 732
Checklist for Monitoring the CFEBs
Purpose You monitor redundant Compact Forwarding Engine Boards (CFEBs) in the M10i router.
A CFEB provides route lookup, filtering, and switching on incoming data packets, then
directs outbound packets to the appropriate interface for transmission to the network.
(See Table 159 on page 729.)
The M10i router CFEB can process 16 million packets per second (Mpps).
The CFEB communicates with the Routing Engine using a dedicated 100-Mbps Fast
Ethernet link that transfers routing table data from the Routing Engine to the forwarding
table in the integrated ASIC. The link is also used to transfer from the CFEB to the Routing
Engine routing link-state updates and other packets destined for the router that have
been received through the router interfaces.
Action Table 159: Checklist for Monitoring the CFEB
Command or ActionMonitor CFEB Tasks
show chassis hardware
“Display Redundant CFEB Hardware
Information” on page 731
“Display CFEB Mastership” on page 732
Look at the LEDs on the CFEB faceplate located
on the rear of the router above the power
supplies.
1. Check CFEB LEDs on page 732
show chassis cfeb2. Display the CFEB Status on page 732
See “Check for CFEB Alarms” on page 523. For
conditions that trigger CFEB alarms, see
“Display the Current Router Alarms” on page 67.
Display CFEB Alarms
See “Verify CFEB Failure” on page 526.
Verify CFEB Failure
729Copyright © 2012, Juniper Networks, Inc.
