Action To display the current PCG alarms, use the following command:
user@host> show chassis alarms
Sample Output
user@host> show chassis alarms
2 alarms currently active
Alarm time Class Description
2002-06-11 20:30:29 PDT Minor PCG 0 Not Online
2002-06-11 20:30:32 PDT Minor No PCGs Online
Meaning The command output displays the alarm date, time, severity level, and description.
Related
Documentation
Checklist for Monitoring Redundant PCGs on page 703•
Replace a PCG
The PCGs are hot-pluggable. You can remove and replace them without powering down
the router; however, the routing functions of the system are interrupted when the PCG
is removed.
If both PCGs are installed and functioning normally, PCG0 is the master PCG and PCG1
is the backup by default.
Removing the backup PCG does not affect the functioning of the router. Taking the master
PCG offline causes the Flexible PIC Concentrators (FPCs) and Switching and Forwarding
Modules (SFMs) to power down and restart, with the other PCG selected as master. The
forwarding and routing functions are interrupted during this process.
To remove and replace a PCG:
1. Lay an electrostatic bag or antistatic mat on a flat, stable surface to receive the PCG.
2. Attach an electrostatic discharge (ESD) strap to your bare wrist, and connect the
strap to one of the ESD points on the chassis.
3. Remove the rear component cover by loosening the screws at the corners of the cover
and pulling it straight off of the chassis.
4. Press and hold the offline button on the PCG faceplate until the yellow LED labeled
FAIL lights, which takes about 3 seconds.
If you are removing the master PCG, forwarding halts while the Packet Forwarding
Engine resets so that the components start using the clock signal from the other PCG,
which becomes the master.
5. Loosen the mounting screw on the right edge of the PCG faceplate, using a Phillips
screwdriver if necessary.
6. Grasp the screw and slide the PCG about halfway out of the chassis.
Copyright © 2012, Juniper Networks, Inc.710
M Series and T Series Routers Monitoring and Troubleshooting Guide
