Juniper M Series User Manual

Figure 195: TX Matrix Plus Router Routing Engine Component
g004506
Related
Documentation
Checklist for Monitoring the Host Subsystem on page 367•
M120, M320, T320, T640, T1600, TX Matrix, and TX Matrix Plus Router Control Boards
The following sections describe the Control Board used on each routing platform.
•
M120 Router Control Board on page 371
•
M320 Router Control Board on page 372
•
T320 Router Control Board on page 372
•
T640 Router Control Board on page 373
•
T1600 Router Control Board on page 373
•
TX Matrix Router Control Board on page 373
•
TX Matrix Plus Router Control Board on page 374
M120 Router Control Board
Figure 196 on page 372 shows the Control Board component used on the M120 router.
371Copyright © 2012, Juniper Networks, Inc.
