CHAPTER 32
Monitoring Redundant SIBs
•
Checklist for Monitoring Redundant SIBs on page 649
•
Understanding Redundant SIBs on page 650
•
Display Redundant SIB Hardware Information on page 653
•
Display SIB Redundancy Information on page 653
Checklist for Monitoring Redundant SIBs
Purpose You monitor and maintain redundant Switch Interface Boards (SIBs) installed in the
M320 and T320 routers and the T640 router to ensure that there is no interruption of
switching function to the destination Flexible PIC Concentrator (FPC). The SIBs create
the switch fabric, providing up to a total of 640 million packets per second (Mpps) of
forwarding.
Table 145 on page 649 provides a checklist of tasks for you to perform to monitor redundant
SIBs.
Action Table 145: Checklist for Monitoring Redundant SIBs
Command or ActionMonitor Redundant SIB Tasks
show chassis hardware
“Display Redundant SIB Hardware
Information” on page 653
show chassis sib
show chassis environment sib
“Display SIB Redundancy Information” on
page 653
See “Monitoring the SIBs” on page 413.
Monitoring Redundant SIB Status
See “Displaying SIB Alarms” on page 424.
Display SIB Alarms
See “Verifying SIB Failure” on page 426.
Performing a Swap Test on a SIB
Locate the serial number label on the left side
of the SIB top panel, and follow the procedure
“Return the Failed Component” on page 116. Or
follow the procedure in the appropriate router
hardware guide.
Returning the SIB
649Copyright © 2012, Juniper Networks, Inc.
