Rear Suspension: 2C-16
Specifications
Service Data
B931G22307001
Suspension
Unit: mm (in)
Tightening Torque Specifications
B931G22307002
NOTE
The specified tightening torque is described in the following.
“Rear Suspension Components (Page 2C-1)”
“Rear Suspension Assembly Construction (Page 2C-2)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Special Tools and Equipment
Recommended Service Material
B931G22308001
NOTE
Required service material is also described in the following.
“Rear Suspension Components (Page 2C-1)”
“Rear Suspension Assembly Construction (Page 2C-2)”
Item Standard Limit
Rear shock absorber spring adjustor 2/5 position —
Fastening part
Tightening torque
Note
N⋅m kgf-m lbf-ft
Rear shock absorber mounting nut
60 6.0 43.5
)(Page 2C-3) /
)(Page 2C-9)
Rear knuckle end nut (Upper and Lower) 60 6.0 43.5 )(Page 2C-5)
Rear wheel hub nut 121 12.1 87.5 )(Page 2C-6)
Suspension arm lower pivot nut 60 6.0 43.5 )(Page 2C-8)
Rear stabilizer joint nut [Up to
5SAAR41A497105526]
34 3.4 24.5
)(Page 2C-9) /
)(Page 2C-15)
Rear stabilizer joint nut [From
5SAAR41A497105527]
60 6.0 43.5
)(Page 2C-9) /
)(Page 2C-15)
Suspension arm upper pivot nut 60 6.0 43.5 )(Page 2C-9)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SILICONE GREASE or
equivalent
P/No.: 99000–25100 )(Page 2C-14)
Water resistance grease or
equivalent
P/No.: 99000–25160 )(Page 2C-5) / )(Page 2C-
5) / )(Page 2C-7) /
)(Page 2C-8) / )(Page 2C-
11) / )(Page 2C-13) /
)(Page 2C-14)
Thread lock cement THREAD LOCK CEMENT SUPER
1303 or equivalent
P/No.: 99000–32030 )(Page 2C-3) / )(Page 2C-
8) / )(Page 2C-15)
