0B-10 Maintenance and Lubrication:
Spark Arrester Cleaning
B931G20206006
Spark arrester cleaning
Every 2 000 km (1 200 miles, 6 months)
1) Remove the muffler end cover (1).
2) Remove the spark arrester (2) from the muffler.
3) Clean the spark arrester (2) with a brush.
4) After finishing the spark arrester cleaning, reinstall
the removed parts.
Fuel Line Inspection
B931G20206007
Inspect fuel line
Every 1 000 km (600 miles, 3 months)
Replace fuel line
Every 4 years
Inspect the fuel line in the following procedures:
1) Remove the left side cover. Refer to “Front Side
Exterior Parts Removal and Installation in Section
9D (Page 9D-6)”.
2) Remove the rear fender. Refer to “Rear Side Exterior
Parts Removal and Installation in Section 9D
(Page 9D-9)”.
3) Remove the fuel tank side cover. Refer to “Fuel Tank
Removal and Installation in Section 1G (Page 1G-
8)”.
4) Inspect the fuel feed hose for damage and fuel
leakage. If any defects are found, the fuel feed hose
must be replaced.
5) After finishing the fuel feed hose inspection or
replacement, reinstall the removed parts.
Engine Oil and Filter Replacement
B931G20206008
Replace engine oil
Initially at 200 km (100 miles, 1 month) and every 2
000 km (1 200 miles, 6 months) thereafter
Replace oil filter
Initially at 200 km (100 miles, 1 month) and every 2
000 km (1 200 miles, 6 months) thereafter
Oil should be changed while the engine is warm. Oil filter
replacement at the above intervals, should be done
together with the engine oil change.
1
I831G1020006-02
2
I831G1020007-03
2
I831G1020008-03
I831G1020019-02
