9B-3
Lighting Systems:
Auxiliary Headlight Component
s
B831G29206005
Auxiliary Headlight Removal and Inst
allation
B831G29206006
Removal
1)
Remove t
he screws (1
).
2)
Remove the auxiliary he
adlight cover (2) by
removing the fasteners (3).
FWD
FWD
1
I831G1920009-05
1.
Auxiliary headlight bulb (12 V 35/35 W)
1
I831G1920010
-01
3
I831G192001
1-01
3
3
2
2
I831G1920012
-01
539
541
