Differential: 3B-3
Front Drive (Differential) Construction
B831G23206002
(a)
2
1
1
“A”
I831G1320002-07
1. Shim : 1.3 N⋅m (0.13 kgf-m, 0.94 lb-ft) : Apply thread lock to the thread part.
2. Front drive (differential) case cover bolt : Apply grease. : Apply bond to matching surface.
“A”: Matching surface : Apply water resistance grease. : Apply molybdenum oil solution.
