Propeller Shafts: 3D-23
Specifications
Service Data
B831G23407001
Drive Train
Unit: mm (in)
Tightening Torque Specifications
B831G23407002
NOTE
The specified tightening torque is also described in the following.
“Rear Output Shaft Components (Page 3D-6)”
“Rear Propeller Shaft Components (Page 3D-17)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Special Tools and Equipment
Recommended Service Material
B831G23408001
NOTE
Required service material is also described in the following.
“Front Output Shaft Components (Page 3D-1)”
“Rear Output Shaft Components (Page 3D-6)”
“Front Propeller Shaft Components (Page 3D-14)”
“Rear Propeller Shaft Components (Page 3D-17)”
Item Standard Limit
Front/Rear output shaft bevel gear
backlash
0.03 – 0.15 (0.001 – 0.006) —
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Rear output shaft drive bevel gear nut
100 10.0 72.5
)(Page 3D-7) /
)(Page 3D-11)
Rear output shaft nut
100 10.0 72.5
)(Page 3D-9) /
)(Page 3D-19)
Rear output shaft driven gear nut 100 10.0 72.5 )(Page 3D-9)
Front propeller shaft boot clamp screw 1.3 0.13 1.0 )(Page 3D-15)
Rear propeller shaft boot clamp screw 2 0.2 1.5 )(Page 3D-20)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 3D-2) / )(Page 3D-
4) / )(Page 3D-4) /
)(Page 3D-19)
Water resistance grease P/No.: 99000–25160 )(Page 3D-4) / )(Page 3D-
9) / )(Page 3D-15) /
)(Page 3D-15) /
)(Page 3D-15) /
)(Page 3D-19) /
)(Page 3D-21) /
)(Page 3D-21) /
)(Page 3D-21)
Thread lock cement THREAD LOCK CEMENT SUPER
1303 or equivalent
P/No.: 99000–32030 )(Page 3D-9) / )(Page 3D-
19)
