3D-16 Propeller Shafts:
Front Propeller Shaft Related Parts Inspection
B831G23406012
Refer to “Front Propeller Shaft Removal and Installation
(Page 3D-14)”.
Front Propeller Shaft
Inspect the front propeller shaft for wear or damage. If
any defects are found, replace the front propeller shaft
with a new one.
Front Propeller Shaft Spring
Inspect the front propeller shaft spring for damage or
fatigue. If any defects are found, replace the front
propeller shaft spring with a new one.
Universal Joint
Inspect the play by turning the universal joint. If
excessive play is noted, replace it with a new one.
CAUTION
!
Do not attempt to disassemble the universal
joint.
Boots
Inspect the front propeller shaft boot (1) and universal
joint boot (2) for crack or damage. If any defects are
found, replace the boot part with a new one.
I831G1340053-01
I831G1340054-01
I831G1340055-01
1
2
I831G1340056-01
To Next Page
