Body Structure: 9E-4
Front Carrier Removal and Installation
B831G29506005
Removal
1) Remove the front grill upper cover. Refer to “Front
Side Exterior Parts Removal and Installation in
Section 9D (Page 9D-6)”.
2) Remove the front carrier (1) by removing the bolts
(2).
Installation
Install the front carrier in the reverse order of removal.
Pay attention to the following point:
• Apply thread lock to the front carrier mounting bolts.
: Thread lock cement 99000–32110
(THREAD LOCK CEMENT SUPER 1322 or
equivalent)
2
I831G1950007-01
2
I831G1950008-02
2
1
I831G1950009-01
I831G1950010-01
I831G1950011-01
