Transfer: 3C-9
• When installing the gear bushing onto the counter
shaft, align the shaft oil hole “C” with the bushing oil
hole “D” as shown in the figure.
Gearshift Cam Components
B831G23306005
“C”
“D”
I831G1330033-05
“D”
“C”
I831G1330034-03
FWD
FWD
5
1
7
8
9
10
13
16
17
20
22
21
2
3
11
12
15
4
14
18
18
19
6
I831G1330003-05
1. Gear position switch 10. Snap ring 19. Snap ring
2. O-ring 11. Bearing 20. Gearshift shaft No. 2
3. Gearshift shaft No. 1 12. Gearshift cam stopper plate 21. Shift gear
4. Snap ring 13. Reverse gearshift fork 22. Shift arm return spring
5. Reverse gearshift cam 14. High/Low gearshift fork : Apply grease.
