9E-7 Body Structure:
Trailer Towing Construction
B831G29506009
Trailer Towing Removal and Instruction
B831G29506010
Removal
Remove the trailer towing (1).
Installation
Install the trailer towing with the trailer towing mounting
bolts and then tighten them to the specified torque.
Tightening torque
Trailer towing mounting bolt (a): 60 N·m (6.0 kgf-m,
43.5 lb-ft)
FWD
“a”
“b”
1
3
2
FWD
(a)
I831G1950020-04
1. Trailer towing warning label (P-17, 28) : 60 N⋅m (6.0 kgf-m, 43.5 lb-ft)
2. Trailer towing warning label “a“: 5 mm (0.2 in)
3. Trailer towing “b“: 30 mm (1.2 in)
1
I831G1950021-01
(a)
I831G1950022-01
