Body Structure: 9E-6
Front Grip Bar Construction
B831G29506007
Front Grip Bar Removal and Installation
B831G29506008
Removal
1) Remove the front carrier. Refer to “Front Carrier
Removal and Installation (Page 9E-4)”.
2) Remove the front cover. Refer to “Front Side Exterior
Parts Removal and Installation in Section 9D
(Page 9D-6)”.
3) Remove the front grip bar (1) by removing the bolt
(2).
Installation
Install the front grip bar in the reverse order of removal.
Pay attention to the following point:
• Apply thread lock to the front grip bar mounting bolts.
: Thread lock cement 99000–32110
(THREAD LOCK CEMENT SUPER 1322 or
equivalent)
FWD
To Next Page
