Combination Meter / Fuel Meter / Horn: 9C-8
Horn Inspection (For P-17, 24)
B831G29306014
NOTE
If the horn sound condition is normal, it is not
necessary to inspect the horn button
continuity.
Horn Button Inspection
1) Disconnect the horn couplers as shown in the wiring
harness routing diagram. Refer to “Wiring Harness
Routing Diagram in Section 9A (Page 9A-4)”.
2) Inspect the horn button for continuity with a tester.
If any abnormality is found, replace the horn button
with a new one.
Refer to “Handlebars Removal and Installation in
Section 6B (Page 6B-3)”.
Special tool
: 09900–25008 (Multi-circuit tester set)
Tester knob indication
Continuity ( )
3) Connect the horn couplers.
Horn Inspection
1) Disconnect the horn couplers as shown in the wiring
harness routing diagram. Refer to “Wiring Harness
Routing Diagram in Section 9A (Page 9A-4)”.
2) Connect a 12 V battery to terminal and terminal. If
the sound is not heard from the horn, replace the
horn with a new one.
3) Connect the horn couplers.
Horn Removal and Installation (For P-17, 24)
B831G29306015
Removal
Disconnect the horn couplers and remove the horn by
removing the mounting nut as shown in the wiring
harness routing diagram. Refer to “Wiring Harness
Routing Diagram in Section 9A (Page 9A-4)”.
Installation
Install the horn in the reverse order of removal.
Specifications
Service Data
B831G29307001
Wattage
Unit: W
Tightening Torque Specifications
B831G29307002
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Color
Position
G B/W
PUSH
I831G1930024-03
Item
Specification
P-24, 28, 33 P-17
Speedometer light LED ←
High beam indicator light — LED
Neutral indicator light LED ←
FI indicator light/Engine coolant temp.
indicator light
LED ←
Reverse indicator light LED ←
Differential lock indicator light LED ←
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Speed sensor mounting bolt 10 1.0 7.0 )(Page 9C-6)
To Next Page
