4A-15 Brake Control System and Diagnosis:
Specifications
Service Data
B831G24107001
Brake
Unit: mm (in)
Oil
Tightening Torque Specifications
B831G24107002
NOTE
The specified tightening torque is also described in the following.
“Front Brake Hose Routing Diagram (Page 4A-1)”
“Front Brake Master Cylinder Components (Page 4A-9)”
“Rear Brake Pedal Construction (Page 4A-13)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Item Standard Limit
Rear brake pedal height 12.5 – 22.5 (0.5 – 0.9) —
Front master cylinder bore 14.000 – 14.043 (0.5512 – 0.5529) —
Front master cylinder piston diam. 13.957 – 13.984 (0.5495 – 0.5506) —
Item Specification Note
Brake fluid type DOT 4
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Front brake air bleeder valve
60.6 4.5
)(Page 4A-6) /
)(Page 4A-7)
Brake pipe flare nut 16 1.6 11.5 )(Page 4A-7)
Master cylinder holder bolt (Upper and Lower) 10 1.0 7.0 )(Page 4A-10)
Brake hose union bolt 23 2.3 16.5 )(Page 4A-10)
Brake lever pivot bolt 6 0.6 4.5 )(Page 4A-12)
Brake lever pivot bolt lock-nut 6 0.6 4.5 )(Page 4A-12)
Rear brake pedal pivot nut 11 1.1 8.0 )(Page 4A-14)
