Exterior Parts: 9D-9
5) Remove the front fender (2) by removing the screws
(3) and fasteners (4).
Installation
Install the front fender in the reverse order of removal.
Rear Side Exterior Parts Removal and
Installation
B831G29406006
Engine Side Cover
Removal
Remove the engine side cover (1).
Installation
Install the engine side cover in the reverse order of
removal.
Rear Box
Removal
Remove the rear box (1).
Installation
Install the rear box in the reverse order of removal.
3
I831G1940018-01
4
3
3
4
I831G1940019-01
4
2
I831G1940020-01
1
I831G1940021-01
1
I831G1940022-01
