Toshiba e-STUDIO556 User Manual

4
© 2012 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO556/656/756/856(Ver03)
DISASSEMBLY AND REPLACEMENT
4 - 5
4.1.12 Left rear cover
4.1.13 Rear cover
(1) Remove 1 screw to take off the left rear
cover.
Fig. 4-13
(1) Loosen 1 screw fixing the ozone filter.
(2) Remove 8 screws. Then release 2 hooks to
take off the rear cover.
Fig. 4-14
Left rear cover
