SELF-DIAGNOSTIC MODE
5 - 24
5.11.3 Functions
[A] Check of the File System (Check F/S)
In case that particular service calls occur or there is a possibility of damage to the file system, the status
of each partition in the HDD can be checked.
Fig. 5-15
Explanation for each item
• 1: Checks all partitions.
• 2: Checks root partition only.
• 3-7: Checks each partition shown above.
Note:
More than one partition can be selected. (">" is displayed on the left of the selected number.)
* If damage is discovered, recover or initialize the file system (HDD).
[B] Recovery of the File System (Recovery F/S)
In case that an error occurs during the file system check, each partition can be recovered.
Fig. 5-16
Explanation for each item
• 1: Recovers all partitions.
• 2: Recovers root partition only.
• 3-7: Recovers each partition shown above.
Remark:
More than one partition can be selected. (">" is displayed on the left of the selected number.)
File System(F/S) Recovery Mode -> Check F/S
Please Select Partition 0: Main menu
1. ALL
2. /
3. /work
4. /registration
5. /backup
6. /imagedata
7. /storage
File System(F/S) Recovery Mode -> Recovery F/S
Please Select Partition 0: Main menu
1. ALL
2. /
3. /work
4. /registration
5. /backup
6. /imagedata
7. /storage
