e-STUDIO556/656/756/856(Ver03) © 2012 TOSHIBA TEC CORPORATION All rights reserved
OUTLINE OF THE MACHINE
3 - 50
3.8.2 Construction
Scanner
Original glass Original glass
RADF original glass
Carriage-1 Exposure lamp (EXP) Xenon lamp (35W)
Inverter board (INV)
Reflector
Mirror-1
Carriage-2 Mirror-2
Mirror-3
Lens unit
CCD driving PC
board (CCD)
Automatic original
detection sensor
(S1-5)
Driving section Scan motor (M1) • 2-phase stepping motor
• Wire drive
• Driving the carriage-1 and carriage-2
Other Scanning section control PC board (SLG)
Carriage home position sensor (S6)
Platen sensor (S53)
Rubber damper
SLG board cooling fan (M23)
Exposure lamp cooling fan-1 (M36)
Scanner unit cooling fan-1 (M38)
Exposure lamp cooling fan-2 (M37)
