SELF-DIAGNOSTIC MODE

5 - 29

Notes:

• When "0" is keyed in and the [START] button is pressed, the menu to key in the serial number

appears. Key in the serial number of this equipment and then press [OK] to determine the

setting.

• Items 1 and 2 can be canceled while 0 and 3 cannot.

• When "3" is keyed in and the [START] button is pressed, the operation starts.

5.12.3 Functions

[A] 0. Set Serial Number

When replacing SYS-SRAM, select this to set the serial number of the equipment since it must be done

in advance of recovery from SRAM backup data.

• Clear SRAM first and then set the serial number in this mode.

• Recover from SRAM backup data after setting the serial number. (Refer to  P.12-2 "12.1.4

Cloning procedure")

Select "0" and then press the [START] button. Then key in the serial number of this equipment.

The keyed in serial number appears on the menu.

Fig. 5-23

[B] 1. Clear SRAM

Select this to clear all SRAM data when replacing SYS-SRAM.

• Replace the SRAM board and then clear the SRAM data.

• After clearing the SRAM data, initialize SRAM following its replacement procedure.

[C] 2. Reset Date and Time

Select this to clear an F800 error which occurred when the date and time were set as after the end of

the year 2037 or when the actual end of the year 2037 has come.

• After selecting this, start the equipment in the normal mode to reset the date and time.

SRAM Clear Mode System Firmware Version

Update Mode

: xxxx(x.x.x.x)

: 6c Mode

0. Set Serial Number

1. Clear SRAM

2. Reset Date and Time

3. SRAM Re-Initialize Support

Serial Number Setting Complated.. xxxxxxxxxx
