ERROR CODE AND TROUBLESHOOTING
8 - 34
8.2.9 Error history
In the setting mode (08-9703), the latest twenty groups of error data will be displayed.
Display example
EA10
99999999 05 03 10 17 57 32 064 064 23621000000
Error code Total counter YY MM DD HH MM SS MMM NNN ABCDEFHIJLOPQ
4 digits 8 digits 12 digits (Year is indicated
with its last two digits.)
3 digits 3 digits 13digits
A Paper source
0: Not selected 1: Bypass feed 2: Tandem LCF 3: 1st drawer 4: 2nd drawer 5: 3rd drawer 6: 4th drawer
7: Option LCF 8: Inserter
B Paper size code
0: A5/ST 1: A5-R 2: ST-R 3: LT 4: A4 5: B5-R 6: LT-R 7: A4-R 8: OTHER/UNIV 9: B5
A: FOLIO/COMP B: LG C: B4 D: LD E: A3 F: 13” LG G: Unused H: A6-R I: Postcard
J: 8.5SQ K: Unused L: Unused M: 8K N: 16K-R O: 16K P: Unused Q: Unused R: Unused
S: Unused T: Unused U: Unused V: Unused Z: Not selected
C Sort mode/staple mode
0: Non-sort/Non-staple 1: Group 2: Sort 7: Front staple 8: Double staple 9: Rear staple
A: Saddle stitch
D ADF mode
0: Unused 1: AUTO FEED (SADF) 2: STACK FEED
E APS/AMS mode
0: Not selected 1: APS 2: AMS
F Duplex mode
Copy:
0: Single-sided/Single-sided 1: Book 2: Double-sided/Single-sided 4: Double-sided/Duplex copying
8: Single-sided/Duplex copying
Printer:
0: Single-sided/Single-sided 8: Single-sided/Duplex printing
FAX:
0: Single-sided/Single-sided 8: Single-sided/Duplex printing
e-Filing Box:
0: Single-sided/Single-sided 8: Single-sided/Duplex printing
List printing:
0: Single-sided/Single-sided printing
GUnused
H Image shift
0: Unused 1: Book 2: Left 3: Right 4:Top 5: Bottom 6: Book+Top 7: Book+Bottom 8: Left+Top
9: Left+Bottom A: Right+Top B: Right+Bottomt
I Editing
0: Unused 1: Masking 2: Trimming 3: Mirror image 4: Negative/Positive Reversal 5: Unused
J Edge erase/Dual-page
0: Unused 1: Edge erase 2: Dual-page 3: Edge erase & Dual-page
KUnused
L Function
0: Unused 1: Copying 2: FAX/Internet FAX transmission
3: FAX/Internet FAX/E-mail reception printing 4: Unused 5: Printing/List print
6: Scan/E-mail transmission
MMM Primary scanning reproduction ratio (Display in hexadecimal)
(Mx256)+(Mx16)+M
NNN Secondary scanning reproduction ratio (Display in hexadecimal)
(Nx256)+(Nx16)+N
O Mode
0: Unused 1: Unused 2: Black 3: Unused 4: Unused
5: Gray scale (Scan) 6: Unused 7:Unused
