6.18.4 Check of sensor operations 2
This is a mode 2 to check each sensor operation separately.
(1) Turn ON the power with pressing the control panel mode key and start key. (The start LED blinks
in green.)
(2) Press the mode key and set up the mode LED1, 2 to blink and mode LED3, 4 to light OFF, and
press the start key. (The start LED lights ON in green.)
* With pressing the mode key for more than 1 sec., all the mode LED light OFF and become
able to be reset.
(3) Check the ON/OFF status of each sensor through the mode LED display.
* The display is switched whenever the start key is pressed.
LED display
When the start switch is OFF:
When the start switch is ON:
Mode LED Display Sensor status
LED1 Light OFF Joint sensor OFF
Light ON Joint sensor ON
LED2 Light OFF Tray open/close sensor OFF
Light ON Tray open/close sensor ON
LED3 Light OFF Transport cover 1 open/close
sensor OFF
Light ON Transport cover 1 open/close
sensor ON
LED4 Light OFF Transport cover 2 open/close
sensor OFF
Light ON Transport cover 2 open/close
sensor ON
Mode LED Display Sensor status
LED1 Light OFF Dip-switch 1 OFF
Light ON Dip-switch 1 ON
LED2 Light OFF Dip-switch 2 OFF
Light ON Dip-switch 2 ON
LED3 Light OFF Dip-switch 3 OFF
Light ON Dip-switch 3 ON
LED4 Light OFF Dip-switch 4 OFF
Light ON Dip-switch 4 ON
