e-STUDIO556/656/756/856(Ver03) © 2012 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
5 - 12
5.7 Test print pattern in Adjustment Mode (05)
Operation: One test print is printed out when the [FAX] button is pressed after the code is keyed in at
Standby Screen.
Code Types of test pattern Remarks
1 Grid pattern (same as 04-142) Refer to  P.6-10 "6.3.3 Printer related
adjustment"
3 Grid pattern 04-142 (Duplex printing) Thick paper not available
Refer to  P.6-10 "6.3.3 Printer related
adjustment"
6
Gamma check patch chart for copia (black) (same
as 04-103)
Refer to  P.6-6 "6.3.2 Paper alignment at the
registration roller"
10 Gamma adjustment patch chart for copia (black)
(Same 04-101)
Refer to  P.6-6 "6.3.2 Paper alignment at the
registration roller"
58 Leading edge position adjustment 04-142 (Thick
paper 2 mode)
For Thick paper 2
59 Leading edge position adjustment 04-142 (Thick
paper 3 mode)
For Thick paper 3
60 Leading edge position adjustment 04-142 (OHP
film mode)
For OHP films
101 Grid pattern – 1 (Black / Thick paper 1) For Thick paper 1(same as 04-113, THICK1)
