Fax Unit Configuration
SM 177 D346
Fax Option
Type 5000
D346
6.4 FAX UNIT CONFIGURATION
Component Code No. Remarks
MBU 7
FCU 6
Speaker
D346
1
Included with fax unit
Expansion Memory G578 2 Optional
CCU I/F Board 3
SG3 Board
D346
4
Optional
SG3 Board D346 5 Optional
Handset Type 1018 B433 - NA only. Also used with Ap-C1
