Controller Options
SM 2-87 D009/D011/D012/D013/D091/D092
Installation
2.21.4 BLUETOOTH
 Unplug the main machine power cord before you do the following procedure.
You can only install one of the following network interfaces at one time: (IEEE 802.11a/g, g
(Wireless LAN), IEEE1284, IEEE1394, Bluetooth).
1. Remove the slot cover [1] from the board Slot ( x 2).
2. Install the Bluetooth board (Knob-screw x 2) into the board slot.
3. Insert the Bluetooth card into the Bluetooth card adaptor.
4. Attach the antenna cap to the Bluetooth card.
5. Install the Bluetooth card adaptor into the Bluetooth board.
6. Make sure that the machine can recognize the option (see "Check All Connections" at
the end of this section).
To Next Page
