Development
SM 4-41 D009/D011/D012/D013/D091/D092
Replacement
&
Adjustment
4.8.2 DEVELOPMENT ROLLER
1. PCDU ( p.4-32)
2. Open the PCDU. (
p.4-33)
3. Upper development cover (
p.4-40)
4. Development roller [A]
 Work carefully to avoid scratching or nicking the development roller.
Cleaning Procedure
1. PCDU ( p.4-32
2. Remove the two screws [A] and open the PCDU as shown above.
