Overview
D009/D011/D012/D013/D091/D092 1-6 SM
1.4 OVERVIEW
1.4.1 COMPONENT LAYOUT
1 Exposure Glass 22 By-pass Feed Roller
2 2nd Mirror 23 By-pass Separation Roller
3 1st Mirror 24 Duplex/by-pass transport roller
4 Exposure Lamp 25 Upper Relay Roller
