Output Check
SM Appendix 4-255 D009/D011/D012/D013/D091/D092
Appendix:
Service
Program
Mode Tables
4.10.2 1000-SHEET FINISHER (B408)
6144 Display Description
6144 1 Relay Up Motor Upper Transport Motor
6144 2 Relay Down Motor Lower Transport Motor
6144 3 Exit Motor -
6144 4
Proof Junction
Gate SOL
Tray Junction Gate Solenoid
6144 5 Tray Up Motor Lower Tray Lift Motor
6144 6 Jogger Motor Jogger Fence Motor
6144 7
Staple Moving
Motor
Stapler Motor
6144 8 Staple Motor Stapler Hammer
6144 9
Staple Junction
Gate SOL
Stapler Junction Gate Solenoid
6144 10
Positioning Roller
Solenoid
Positioning Roller Solenoid
6144 11
Stack Feed-out
Motor
-
6144 12 Shift Motor -
6144 13
Exit Guide Plate
Motor
-
