1200-Sheet LCT (D353)
SM 2-27 D009/D011/D012/D013/D091/D092
Installation
2.6 1200-SHEET LCT (D353)
2.6.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q'ty
1 Front Bracket 1
2 Rear Bracket 1
3 Stud Screw 4
4 Joint Pin 2
5 LCT 1
