By-pass
D009/D01
1/D012/D013/D091/D092 4-80
SM
4.14.3
BY-PASS PICK-UP, FEED
AND SEPARATION ROLLER,
TORQUE LIMITER
1.
Right door cover (
p.4-72)
2.
By-pass feed unit cover (
p.4-79)
3.
By-pass pick-up roller [A] (hook)
4.
By-pass feed roller [B] (
x
1)
5.
By-pass sep
aration roller [C] (
x
1)
6.
T
orque limiter [D]
249
251
