System SP Table-1
D009/D011/D012/D013/D091/D092 4-4 SM Appendix
003 Idling Time at Every Job
Sets the machine to fusing idling only for 30
sec. for every job (when the original is set on
the ARDF, when the ARDF cover is opened,
etc.) and the fusing unit has reached the
reload temperature (optimum temperature for
operation).
[0 to 30 / 0 / 1 sec.]
0: No idling done before a job.
1104*
Fusing Temperature Control
On-Off/Phase
Selects the fusing temperature control method. After changing this setting,
be sure to turn the machine off and on again with the main power switch to
enable the new setting.
[0 to 1 / 0 / 1]
0: Normal (ON/OFF control). Allows full application from ac power supply to
bring the hot roller up to the target fusing temperature then shuts off.
Determines the on-time from the present temperature (detected by the
thermistor on the hot roller) and the temperature of 1 cycle before.
1: Phase (hysterisis) control. Sets the upper and lower limits for the
temperature; at the lower temperature the fusing lamp is on and at the
higher temperature the fusing lamp is off.
Change this setting to "0" only if the user has excessive electrical noise or
interference on the power supply line. Such interference can cause voltage
to drop when power is applied using the ON/OFF control method.
Interference can be caused by the general poor quality of the power supply
lines, or if the machine is sharing a power supply with other electrical
devices such as fluorescent lights. Before changing this setting, make sure
that the machine is connected to a power supply not shared by other
electrical equipment.
 Selecting Phase control ("1") could cause the fusing temperature
control board to emit low pitched noise
