Exterior Covers
SM 4-5 D009/D011/D012/D013/D091/D092
Replacement
&
Adjustment
4.3.4 RIGHT REAR COVER
1. Rear cover( p.4-4)
2. Open the right door [A].
3. Scanner right cover [B] (
x 2)
4. Right top cover [C] (
x 1)
5. Right rear cover [D] (
x 4)
