NVRAM Data Upload/Download
SM 5-19 D009/D011/D012/D013/D091/D092
Service
Tables
5.5 NVRAM DATA UPLOAD/DOWNLOAD
The content of the NVRAM can be uploaded to and downloaded from an SD card.
IMPORTANT NOTE:
The following data stored in the NVRAM will not be saved on the SD Card when
performing an NVRAM Data Upload (SP5824):
• Total count categories (SP7-003-*** Copy Counter)
• C/O, P/O Counter (SP7-006-*** C/O, P/O Count Display)
• Dupelx, A3/DLT/Over 420 mm, Stapler and Scanner application scanning counters
(system settings).
• Engine SP Data
Therefore, whenever an NVRAM Upload/Download is performed, make sure to print out
the SP Data List before performing SP5801-001 (Memory Clear: All Clear) or SP5801-002
(Memory Clear: Engine).
NVRAM Upload/Download Procedure:
1) Print out the SP Data list from SP5990-002.
2) Perform the NVRAM Data Upload (to the SD Card) according to the procedure
below.
3) Perform the Memory Clear (SP5801-001 or 002).
4) Perform the NVRAM Data Download (from the SD Card) according to the
procedure below.
5) Manually input the data listed above.
5.5.1 UPLOADING NVRAM DATA (SP5-824)
1. Turn OFF the main switch.
2. Remove the SD card cover ( x 1).
3. Insert the SD card into SD card slot 2.
4. Turn ON the main switch.
5. Execute SP5-824.
6. Press to start uploading the NVRAM data.
5.5.2 DOWNLOADING NVRAM DATA (SP5-825)
The following data are not downloaded from the SD card:
• Total counter
• C/O, P/O Counter
• Duplex, A3/DLT/Over 420mm, Staple and scanner application scanning
counters(system setting)
• Engine SP data
1. Out put the SMC data (SP5-990-001)
2. Turn OFF the main switch.
3. Remove the SD card cover
4. Plug the SD card into SD card slot 2.
5. Turn ON the main switch
6. Execute SP5-825
7. Press to start downloading the NVRAM data.
8. Enter Engine SP data (if you performed Engine NVRAM clear SP5-801-002)
⇒
