Service Call Conditions
D009/D011/D012/D013/D091/D092 3-30 SM Appendix
SC Tables: SC7xx
700 D
Original stopper HP error
When the pick-up motor turns on clockwise, the original stopper HP sensor
does not detect the home position of the original stopper.
 Defective original stopper HP sensor
 Defective pick-up motor
 Defective DF drive board
701 D
Pick-up roller HP error
When the pick-up motor turns on counterclockwise, the pick-up roller HP
sensor does not detect the home position of the pick-up roller.
 Defective pick-up roller HP sensor
 Defective pick-up motor
 Defective DF drive board
721 B
Finisher jogger motor error
The jogger fences move out of the home position but the HP sensor output
does not change within the specified number of pulses.
The 1st failure issues an original jam message, and the 2nd failure issues
this SC code.
 Jogger HP sensor disconnected, defective
 Jogger motor disconnected, defective
 Jogger motor overloaded due to obstruction
 Finisher main board and jogger motor
