Paper Feed
SM 19 D353
1200 Sheet
LCT RT3000
D353
Paper End
The paper end sensor [E] monitors the light reflected by each sheet on top of the
stack.
When the last sheet feeds, the cutout [F] is exposed, and the paper end sensor receives no
reflected light from below because there is no paper. As a result, this signals paper end.
