1000-Sheet
Finisher
B408
DIP SWITCH SETTINGS
SM 9 B408
3. SERVICE TABLES
3.1 DIP SWITCH SETTINGS
The DIP switches should not be set to any combination other than those listed in
the table below.
SW100
1 2
Description
0 0 Normal operation mode (Default)
1 0 Packing mode.
• Before packing the machine, do the following: Set switch 1 to 1 then back to
zero. The lower tray moves to the lowest position. Then turn off the main switch.
• After unpacking the machine, do the following: After turning the main switch back
on, the lower tray returns to home position automatically.
