MOTORS
B408 4 SM
1.3.3 UPPER TRANSPORT MOTOR AND EXIT MOTOR
1. Rear cover (
1.1)
2. Motor assembly [A] (
x 4,
x 2)
3. Upper transport motor [B] (
x 4)
4. Exit motor [C] (
x 4)
1.3.4 LOWER TRANSPORT MOTOR
1. Main PCB (
1.1)
2. Lower transport motor [A] (
x 2,
x
1)
B408R112.WMF
B408R111.WMF
[A]
[B]
[C]
[A]
