INSTALLATION REQUIREMENTS
SM 3 B838
Scanner
Accessibility
Option
B838
1.1.3 ACCESSORY CHECK
Check the accessories and their quantities against the following list.
No. Description Q'ty
1 Top Rear Cover 1
2 Rear Bracket 1
3 Key Counter Bracket (only for installing key counter) 1
4 Left Scanner Stay 1
5 Right Bottom Plate 1
6 Left Bottom Plate 1
7 Left Stopper 1
8 Right Stopper 1
9 Cable Bracket Unit 1
10 Operation Panel Interface Board 1
11 MB Interface Board 1
12 Gasket - Scanner Frame 1
13 Gasket - Scanner Lens 1
14 Seal - Bottom 1
15 Ferrite Core 17
16 Shoulder Screw (only for installing key counter) 1
17 Adjuster 2
18 Spacer 2
19 Rubber Leg 3
20 Cap 3
21 Saddle Clamp 1
22 Clamp 1
23 Plate Clamp 4
24 Screw-Round: M4x8 2
25 Screw-Tapping: M3x8 (blue) 7
26 Screw-Round: M3x6 4
27 Screw 2-Tapping: M3x8 4
28 Screw-Tapping: M4x16 4
29 Screw-Tapping: M4x8 4
30 Screw-Tapping: M3x6 5
31 Screw-Tapping: M3x8 6
32 Left Bracket 1
33 Harness - MB 1
34 Harness - Operation Panel Board 1
35 Top Right Cover 1
36 Cable Bracket Cover 1
To Next Page
