Fusing
SM 4-57 D009/D011/D012/D013/D091/D092
Replacement
&
Adjustment
4.11.2 WEB ROLLER UNIT
1. Fusing unit ( p.4-56)
2. Web roller unit [A] (
x 2)
4.11.3 BRAKE PAD
1. Web roller unit ( p.4-57)
2. Web left cover [A] (front:
x 2, rear: stepped screw x 2)
3. Web top frame [B] (
x 2)
