Left and Right Tray
SM 1 D352
LCT PB3050
D352
1. REPLACEMENT AND ADJUSTMENT
1.1 LEFT AND RIGHT TRAY
1. Pull the LCT drawer.
 If the right tray comes up with the left tray, push the right tray into the LCT.
2. Left tray [A] (x 2)
3. Remove the right tray [B] while pressing down the stopper [C].
 When reinstalling the tray, set the tray on the guide rail and carefully push the
tray in, making sure to keep the tray level.
To Next Page
