Other Options
SM 21 D381
Printer/
Scanner
Option
D381
1. Remove the slot cover [1] from the board Slot ( x 2).
2. Install the Bluetooth board (Knob-screw x 2) into the board slot.
3. Insert the Bluetooth card into the Bluetooth card adaptor.
4. Attach the antenna cap to the Bluetooth card.
5. Install the Bluetooth card adaptor into the Bluetooth board.
6. Make sure that the machine can recognize the option (see "Check All Connections" at
the end of this section).
1.3.7 GIGABIT ETHERNET AND USB2.0
 Unplug the main machine power cord before you do the following procedure.
You can only install one of the following network interfaces at one time: (IEEE 802.11a/g, g
(Wireless LAN), IEEE1284, IEEE1394, Bluetooth).
1. Remove the slot cover [1] from the board slot ( x 2).
