Mechanical Component Layout
SM 5 D386
Bridge Unit
BU3030
D386
2. DETAILS
2.1 MECHANICAL COMPONENT LAYOUT
1. Upper Exit Roller
2. Tray Exit Sensor
3. Junction Gate
4. 1st Transport Roller
5. Relay Sensor
6. 2nd Transport Roller
7. Left Exit Roller
8. Paper Tray
