Bit Switches
D346 100 SM
1
Alarm when the handset is
off-hook at the end of
communication
0: Disabled
1: Enabled
If the customer wants to hear an alarm if the
handset is off-hook at the end of fax
communication, change this bit to “1”.
2/3
Not used
Do not change the settings.
4
Sidaa manual calibration
setting
0: Off
1: On
1: manually calibrates for communication with a
line, whose current change occurs such as an
optical fiber line.
5-7
Not used
Do not change the settings.
4.3.6 G3-2/3 SWITCHES
These switches require an optional G3 interface unit.
G3-3 switches are the same as for G3-2 switches.
G3-2 Switch 00 [SP No. 1-106-001]
No FUNCTION COMMENTS
0-1
Monitor speaker during
communication (tx and rx)
Bit 1: 0, Bit 0: 0 = Disabled
Bit 1: 0, Bit 0: 1 = Up to Phase
B
Bit 1: 1, Bit 0: 0 = All the time
Bit 1: 1, Bit 0: 1 = Not used
(0, 0): The monitor speaker is disabled all through
the communication.
(0, 1): The monitor speaker is on up to phase B in
the T.30 protocol.
(1, 0): Used for testing. The monitor speaker is on
all through the communication. Make sure that you
reset these bits after testing.
2
Monitor speaker during
memory transmission
0: Disabled 1: Enabled
1: The monitor speaker is enabled during memory
transmission.
3-7
Not used
Do not change the settings.
